FEATURES
- Standalone MPC – no computer required
- Powerful Multicore System from the MPC Live and MPC X
- 16 velocity-sensitive RGB Pads
- 7-inch high-resolution multi-touch display
- 2GB RAM, 4GB of on-board storage
- Mac & PC Controller for MPC Software (Included)
- Stereo Line-Level Inputs
- MIDI In and MIDI Out
- (8) CV/Gate Outputs using 1⁄8-inch (3.5mm) TRS cables (mono TS cable compatible)
- (2) USB-A 3.0 Slots for thumb drives or MIDI Controllers
- SD card slot
SPECIFICATIONS
Pads
- (16) velocity- and pressure-sensitive pads, RGB-backlit
- (8) banks accessible via Pad Bank buttons
- (4) 360° touch-sensitive Q-Link Knobs
- (4) Q-Link Knob columns accessible via Q-Link button
- (1) 360° encoder for display navigation and selection via push
- (31) dedicated function buttons; red-, amber-, or green-backlit
- 7.0” / 177mm (diagonal)
- 5.9” x 3.7” / 151 x 94mm (width x height)
- Full-color LED-backlit display with touch interface
- Processor: Quad-core ARM processor
- RAM: 2GB
- Storage: 2GB user storage, 2GB pre-installed content
- (2) 1⁄4” (6.35mm) TRS inputs (1 stereo pair)
- (2) 1⁄4” (6.35mm) TRS outputs (1 stereo pair)
- (1) 1⁄8” (3.5mm) stereo headphone output
- (1) 5-pin MIDI inputs
- (1) 5-pin MIDI outputs
- (4) CV/Gate outputs
- (1) USB Type-A port
- (1) USB Type-B port
- (1) SD card slot
- (1) power adapter input
- via power adapter: 19V, 3.42A, center-positive, included
- (width x depth x height)
- 10.7” x 10.7” x 2.1”
- 272 x 272 x 53mm
- 4.7 lbs.
- 2.1kg
